Car turn table

Pin gear car rotating platform is often used for cars in the limited space of the position to turn around, but also mainly used in parking lots, three-dimensional garage, private garage, etc., this product adopts pin tooth transmission technology, the work operation type more stable, stronger bearing capacity, and longer service life at the same time.

Car turn table

Pin gear car rotating platform is often used for cars in the limited space of the position to turn around, but also mainly used in parking lots, three-dimensional garage, private garage, etc., this product adopts pin tooth transmission technology, the work operation type more stable, stronger bearing capacity, and longer service life at the same time.

  • Parameters

Mesa Diameter4M   4.5M   5M   5.5M   6M   7M
Equipment Is Highly310-330mm
Period Of Rotation0.2-1rpm  frequency control
Carrying Capacity4000-8000kg
Kind Of DrivePin gear transmission
Motor Power0.36-1.1KW
Connect Power SupplyAC110V   AC220V   AC380V   selectable
Mesa MaterialDensity board Plywood board plate pattern aluminum alloy board (selectable)
Control ModeManual control/remote control positive and negative rotation remote control Angle control stop position control (selectable)

Custom Design


Advantages

1、The pin tooth plate is processed and formed by an automatic cutting machine with a thickness of 10mm.

Hole making process using CNC boring machine machining template hole making;Pin teeth are processed by 45# steel bar machine, after conditioning (heat treatment) and galvanized or black cooking process as a finished product.


2、Pin-tooth automobile rotating platform USES ac frequency conversion brake motor to drive the reducer and drive the main gear to engage the pin shaft part to drive the rotary table to rotate smoothly.

High strength nylon is selected as the gear material. Nylon gear has excellent mechanical strength, abrasion resistance and corrosion resistance, which can replace metal gear and greatly reduce the noise of equipment operation.


3、Through four supporting bolts, the height of the equipment can be adjusted and the requirements of platform installation on the site environment can be reduced.                                                                                            Nylon is selected as the material of the supporting wheel body for the stable support platform. Nylon wheel has excellent mechanical strength, abrasion resistance and corrosion resistance, which can replace metal gear and greatly reduce the noise of equipment operation.

The center seat can adjust the height of the center seat by adjusting the shaft sleeve device of the center seat

thereby reducing the requirement of equipment installation on site flatness.
